Courtesy lamps circuit for Nissan Armada I (2003-2007)

56 57 62 63 67 70 BAT SAVER BAT (FUSE) STEP LAMP ROOM LAMP GND BAT (F/L) BACK DOOR SWITCH (W/O POWER BACK DOOR) (AT BOTTOM CENTER OF BACK DOOR) BETWEEN FULL STROKE, N BETWEEN FULL STROKE, N BLK WIRE BLK/RED WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND CENTER OF DASH) BRN/WHT WIRE CARGO LAMP COMPUTER DATA LINES SYSTEM FULL STROKE FULL STROKE FUSE 22 FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE 19 FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE COMPT) FUSE 59 FUSIBLE LINK F GLASS HATCH AJAR SWITCH (AT CENTER OF BACK DOOR) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEY SWITCH, KEY LOCK SOLENOID (ON STEERING COLUMN) LEFT FOOT LAMP LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT FRONT STEP LAMP LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR) LEFT REAR STEP LAMP RIGHT REAR STEP LAMP LOCK SWITCH UNLOCK SWITCH LT BLU WIRE LT GRN/WHT WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH OFF ON DOOR PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOT LAMP RIGHT FRONT STEP LAMP RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR) W/O POWER BACK DOOR W/ POWER BACK DOOR WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/PPL WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE DOOR DOOR ON DOOR ON OFF FRONT ROOM/ MAP LAMP ASSEMBLY GRN WIRE IGNITION KEYHOLE ILLUMINATION LEFT DOOR MIRROR (PUDDLE LAMP) LEFT VANITY LAMP OFF PERSONAL LAMP PUDDLE LAMP RED WIRE RED/GRN WIRE RIGHT DOOR MIRROR (PUDDLE LAMP) RIGHT VANITY LAMP WHT WIRE
