Electronic suspension circuit for Nissan Armada I (2003-2007)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PPL COMP RLY OUT BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CK SUSP IND COMBINATION METER COMPRESSOR MOTOR RELAY (AT RIGHT FRONT OF ENGINE COMPT) DATA LINK CONNECTOR (BEHIND LOWER LEFT SIDE OF DASH) EXHAUST VALVE SOLENOID FUSE 12 FUSE 14 FUSE 19 FUSE 29 FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK G GENERATOR GRN/RED WIRE GRN/WHT WIRE HEIGHT SENS HEIGHT SENSOR (AT RIGHT REAR CORNER OF VEHICLE) HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE ORG/BLU WIRE PPL RED WIRE SENS GND ALT IN GND SUSPENSION AIR COMPRESSOR (AT RIGHT REAR CORNER OF VEHICLE) SUSPENSION CONTROL UNIT (BEHIND LEFT REAR QUARTERPANEL) UNIFIED METER CONTROL UNIT VREF OUT IGN BAT K-LINE EXH VLV OUT LAMP OUT WHT WIRE WHT/BLU WIRE YEL/BLK WIRE YEL/RED WIRE
