Car Wiring Diagrams for Defoggers circuit for Nissan Armada I (2003-2007)

10 4 (W/ AUTO DRIVE POSITIONER) (W/O AUTO DRIVE POSITIONER) 14 1 11 IGN GND RR DEF REQ 34 35 CAN-H CAN-L 57 70 67 BAT BAT GND PWR 6 11 (W/O AUTO DRIVE POSITIONER) (W/ AUTO DRIVE POSITIONER) 9 39 40 RR DEF SW CAN-H CAN-L BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND CENTER OF DASH) COMPUTER DATA LINES SYSTEM DOOR MIRROR DEFOGGER FRONT AIR CONTROL FUSE 22 FUSE 43 FUSE 46 FUSE 47 FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F FUSIBLE LINK I GRN WIRE GRY/WHT WIRE HEATED MIRROR RELAY HOT AT ALL TIMES HOT IN ON FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE 8 HOT IN ON OR START IGNITION RELAY IPDM E/R (RIGHT REAR OF ENGINE COMPT) LEFT DOOR MIRROR (AT MIRROR) DOOR MIRROR DEFOGGER PNK WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY RIGHT DOOR MIRROR (AT MIRROR) WHT/BLK WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
