Nissan Armada I (2003-2007) transmissions system Wiring diagrams
This page contains all the electrical diagrams for the component. transmissions system, in which he is found in the car Nissan Armada I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmissions system (1 of 3)
1 2 PNK WIRE
A/T CHECK IND
A/T TEMP GAUGE (TRAILER TOW 7 PIN)
ABS IND.
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
AIR BAG IND
ANTI-THEFT SYSTEM
ATP IND
AUTO IND
AV SWITCH
BELT IND
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE IND PNK WIRE
BRN WIRE
BRN/WHT WIRE
BUZZER
CHARGE IND
COMBINATION METER
CRUISE IND
DISPLAY CONTROL UNIT (BEHIND UPPER CENTER OF DASH) METER ILLUM
DOOR IND
FUEL GAUGE
FUEL IND
FUSE 14
FUSE 19
FUSE 4
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH)
GRN WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/RED WIRE
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IND
LEFT SEAT BELT BUCKLE PRE-TENSIONER ASSEMBLY (SEAT BELT BUCKLE SWITCH)
LEFT TURN IND
LOCK IND
LOW HI
LT GRN/RED WIRE
MALFUNCTION IND LAMP
OIL PRESSURE GAUGE
OIL PRESSURE SWITCH (ON LOWER LEFT FRONT OF ENGINE)
OIL/TEMP IND
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PNK W/L WIRE
PNK/BLK WIRE
RED WIRE
RIGHT TURN IND
SB SW
SECURITY IND
SET IND
SHIFT LOCK CONTROL UNIT (BEHIND RIGHT SIDE OF DASH)
SLIP IND
SPEEDOMETER
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM
TACHOMETER
TIRE PRESSURE IND
TRANSMISSIONS SYSTEM
UNIFIED METER CONTROL UNIT (W/ ODOMETER/TRIP METER)
VCC
VDC OFF IND
VOLT GAUGE
VOUT
WARNING LAMP OUT
WASHER IND
WATER TEMP GAUGE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> TRANSMISSIONS SYSTEM
Wiring diagram transmissions system (2 of 3)
A/C RELAY
AIR CONDITIONING SYSTEM
AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT, HORNS SYSTEMS ANTI-LOCK BRAKES SYSTEM
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CANADA
COOLING FANS SYSTEM
CPU FUSE 36
CPU FUSE 43
CPU FUSE 56
DEFOGGER SYSTEM WIPER/ WASHER SYSTEM HEADLIGHTS SYSTEM
ECM RELAY
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
FROM FUSE 48 (DIAGRAM 2 OF 2)
FROM FUSIBLE LINK L (DIAGRAM 1 OF 2)
FROM IGNITION RELAY (DIAGRAM 2 OF 2)
FRONT WIPER HI RELAY HEATED MIRROR RELAY FRONT FOG LAMP RELAY (IF EQUIPPED)
FRONT WIPER RELAY
FUSE 24
FUSE 27 FUSE 25
FUSE 30
FUSE 31 FUSE 28 FUSE 29
FUSE 34
FUSE 37
FUSE 39
FUSE 42
FUSE 45 FUSE 32
FUSE 52
FUSE 53
FUSIBLE LINK
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK BOX (BATTERY) (AT RIGHT SIDE OF ENGINE COMPT)
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK F FUSE 26
FUSIBLE LINK G
FUSIBLE LINK H
FUSIBLE LINK I
FUSIBLE LINK J
FUSIBLE LINK K
FUSIBLE LINK L
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
INTERIOR LIGHTS, EXTERIOR LIGHTS SYSTEMS
INTERIOR LIGHTS, EXTERIOR LIGHTS, HEADLIGHTS, NAVIGATION SYSTEMS
NAVIGATION, SOUND, WARNING SYSTEMS
NCA WIRE
ORG/ WIRE
PNK WIRE
REAR CARGO POWER SOCKET
RED WIRE
STARTING/ CHARGING SYSTEM
TAIL LAMP RELAY
THROTTLE CONTROL MOTOR RELAY
TO FUSE 3 (DIAGRAM 2 OF 2)
TO FUSE 46 (DIAGRAM 2 OF 2)
TO HEADLIGHT HI RELAY (DIAGRAM 2 OF 2)
TO HEATED MIRROR RELAY (DIAGRAM 1 OF 2)
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, ENGINE CONTROLS, ANTI-THEFT SYSTEMS
W/ REAR LOAD LEVELING AIR SUSPENSION SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> TRANSMISSIONS SYSTEM
Wiring diagram transmissions system (3 of 3)
ACCESSORY RELAY
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM TRANSMISSIONS SYSTEM
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CONSOLE POWER SOCKET
CPU FUSE 40 FUSE 35 FUSE 34
DEFOGGER SYSTEM HEADLIGHTS, ANTI-THEFT SYSTEM
ENGINE CONTROLS SYSTEM
FROM FUSE 43 (DIAGRAM 1 OF 2) FROM ECM RELAY (DIAGRAM 1 OF 2)
FROM FUSE 52 (DIAGRAM 1 OF 2)
FROM FUSE 59 (DIAGRAM 2 OF 2)
FROM FUSIBLE LINK B (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK M (DIAGRAM 1 OF 2)
FRONT DRIVER POWER SOCKET
FRONT PASSENGER POWER SOCKET
FUEL PUMP RELAY
FUSE 11
FUSE 12 FUSE 13 FUSE 14
FUSE 15 FUSE 8
FUSE 16
FUSE 18 FUSE 22 FUSE 19 FUSE 17
FUSE 2 FUSE 9
FUSE 20 FUSE 5
FUSE 3
FUSE 38 FUSE 54
FUSE 4
FUSE 41
FUSE 47 FUSE 46
FUSE 48 FUSE 50 FUSE 51
FUSE 49
FUSE 55
FUSE 57 FUSE 58
FUSE 59
FUSE 6 FUSE 7 FUSE 10
FUSE, RELAY BOX (AT RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
HEADLIGHTS, ANTI-THEFT SYSTEM
IGNITION RELAY
IGNITION SWITCH
LOCK OFF
LT GRN WIRE
MEMORY SYSTEM
MIRRORS SYSTEM
ORG/ WIRE
PNK WIRE
REAR BLOWER MOTOR RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
SEATS SYSTEM
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO A/C RELAY (DIAGRAM 1 OF 2)
TO FRONT WIPER HI RELAY (DIAGRAM 1 OF 2)
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
TRANSMISSIONS, NAVIGATION, EXTERIOR LIGHTS SYSTEMS
VIO WIRE
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> TRANSMISSIONS SYSTEM
