Nissan Armada I (2003-2007) rear sonar sensor off switch Wiring diagram
This page shows the only wiring diagram for the component.rear sonar sensor off switch, which is found in the car Nissan Armada I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear sonar sensor off switch (1 of 1)
12 13 14 15 16 RR INNER RH ENABLE SW
A/T ASSEMBLY TRANSMISSION CONTROL MODULE
BACK-UP LAMP RELAY (IN FUSE, RELAY BOX)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
FUSE BLOCK (J/B) (BEHIND RIGHT END OF DASH) FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT IN ON OR START
ILL
LEFT INNER REAR SONAR SENSOR (AT INNER LEFT SIDE OF REAR BUMPER)
LT GRN WIRE
LT GRN/BLK WIRE
OFF IND
ORG/ WIRE
PNK WIRE
REAR SONAR SENSOR OFF SWITCH
RED WIRE
RED/BLU WIRE
REV LAMP RLY
RIGHT INNER REAR SONAR SENSOR (AT INNER RIGHT SIDE OF REAR BUMPER)
RR SNSR GND RR SNSR PWR
SONAR BUZZER (BEHIND UPPER LEFT SIDE OF DASH)
SONAR CONTROL UNIT (BEHIND LEFT REAR QUARTERPANEL)
YEL WIRE
Go to component -> Rear sonar circuit -> REAR SONAR SENSOR OFF SWITCH
