Nissan Armada I (2003-2007) full stroke lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. full stroke lock switch, in which he is found in the car Nissan Armada I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram full stroke lock switch (1 of 2)
& N
+IG
1 2 3 PNK WIRE
BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
BLU/WHT (OR YEL) WIRE
CAN CAN HORN RLY GND GND
COMPT)
FULL STROKE BETWEEN FULL STROKE
FULL STROKE LOCK SWITCH
FUSE 25
FUSE 34
FUSE 35 FUSE 40
FUSE 41
FUSE 53 FUSE 52
FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE
GRN WIRE
GRN/WHT WIRE
H/LP HI
H/LP LO
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HIGH BEAM
HORN
HORN RELAY (IN FUSE, FUSIBLE LINK BOX)
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
IPDM E/R (AT RIGHT REAR OF ENGINE COMPT)
LEFT FRONT COMBINATION LAMP (HEADLAMP)
LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) (AT REAR OF LEFT FRONT DOOR)
LOW BEAM
PNK WIRE
POWER WINDOW SERIAL LINK
PPL
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP (HEADLAMP) LOW BEAM
RIGHT POWER WINDOW SERIAL LINK POWER WINDOW, DOOR LOCK/UNLOCK CPU SWITCH
UNLOCK LOCK
UNLOCK SWITCH
WHT WIRE
WHT/PPL WIRE
Go to component -> Forced entry circuit (2 of 2) -> FULL STROKE LOCK SWITCH
Wiring diagram full stroke lock switch (2 of 2)
& N
4 5 6 PNK WIRE
BACK DOOR LOCK ACTUATOR (W/O POWER BACK DOOR) (AT CENTER OF BACK DOOR)
BETWEEN FULL STROKE, N
BLK WIRE
BLU WIRE
CAN CAN HORN RLY GND GND
COMPT)
FULL STROKE BETWEEN FULL STROKE
FULL STROKE LOCK SWITCH
FUSE 25
FUSE 53 FUSE 52
FUSE, FUSIBLE LINK BOX (AT RIGHT REAR OF ENGINE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
H/LP LO H/LP HI
HEADLIGHTS SYSTEM
HORN
HORN RELAY (IN FUSE, FUSIBLE LINK BOX)
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IG B+
IGNITION RELAY
IPDM E/R (AT RIGHT REAR OF ENGINE COMPT)
LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) (AT REAR OF LEFT FRONT DOOR)
LOCK
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
PNK WIRE
POWER WINDOW SERIAL LINK
PPL
RED WIRE
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH POWER WINDOW SERIAL LINK
UNLOCK
UNLOCK LOCK
UNLOCK SWITCH
WHT WIRE
WHT/PPL WIRE
Go to component -> Power door locks circuit (2 of 2) -> FULL STROKE LOCK SWITCH
