Nissan Altima U13 (1992-1997) lock input Wiring diagram
This page shows the only wiring diagram for the component.lock input, which is found in the car Nissan Altima U13 (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock input (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
CIRCUIT BREAKER (LEFT SIDE OF DASH)
DOOR LOCK TIMER (BELOW STEERING COLUMN)
FUSE
FUSIBLE LINK, FUSE BOX (LEFT FRONT OF ENGINE COMPARTMENT, NEAR BATTERY)
GROUND
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LOCK INPUT
LOCK/ UNLOCK OUTPUT
MAIN POWER WINDOW AND DOOR LOCK SWITCH
POWER TOPS SYSTEM
RED WIRE
RIGHT DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
UNLOCK
UNLOCK INPUT
WHT WIRE
WHT/RED WIRE
Go to component -> Power door lock circuit -> LOCK INPUT
