Car Wiring Diagrams for Memory seat circuit for Nissan Altima L34 (2018-2024)

ADDRESS 2 ADDRESS-1 AUTOMATIC DRIVE POSITIONER CONTROL UNIT BAT (PTC) BLK WIRE BLU WIRE BRN WIRE BWD CAN-H CIRCUIT BREAKER 2 COMPUTER DATA LINES SYSTEM DN UP DRIVER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT) FRONT LIFTER MOTOR (DOWNWARD) FRONT LIFTER MOTOR (UPWARD) FRONT LIFTER SW (DOWNWARD) FRONT LIFTER SW (UPWARD) FUSE 14 FUSE 3 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK H GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT FRONT LIFTING MOTOR LEFT REAR LIFTING MOTOR LEFT RECLINING MOTOR LEFT SLIDING MOTOR LT BLU WIRE LT GRN WIRE PNK COMPUTER DATA LINES SYSTEM WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWER SUPPLY (ENCODER) PPL PPL/WHT WIRE PULSE (FRONT LIFTER) PULSE (REAR LIFTER) PULSE (RECLINER) PULSE (SLIDE) CAN-L REAR LIFTER MOTOR (DOWNWARD) REAR LIFTER MOTOR (UPWARD) REAR LIFTER SW (DOWNWARD) REAR LIFTER SW (UPWARD) RECLINER MOTOR (BACKWARD) RECLINER MOTOR (FORWARD) RECLINER SW (BACKWARD) RECLINER SW (FORWARD) RED WIRE SET SW SLIDE MOTOR (BACKWARD) SLIDE MOTOR FORWARD SLIDE SW (BACKWARD) IND 2 SLIDE SW (FORWARD) IND 1 UART UART (TX/RX) WHT WIRE YEL WIRE

BACKWARD BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BWD CAN L CAN-H COMPUTER DATA LINES SYSTEM FORWARD/ FRONT LIFTING SWITCH GRN WIRE GRY WIRE LEFT "C" PILLAR) LEFT FRONT DOOR SWITCH LEFT POWER SEAT SWITCH LT BLU WIRE LT GRN WIRE LUMBAR SUPPORT MOTOR LUMBAR SUPPORT SWITCH MEMORY INDICATOR 1 MEMORY INDICATOR 2 MEMORY SWITCH 1 MEMORY SWITCH 2 PNK WIRE PPL PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE PWR ECU REAR LIFTING SWITCH RECLINING SWITCH RED WIRE SEAT MEMORY SWITCH SET SWITCH SLIDING SWITCH YEL WIRE
