Nissan Altima L34 (2018-2024) w/o blind spot warning system Wiring diagram
This page shows the only wiring diagram for the component.w/o blind spot warning system, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o blind spot warning system (1 of 1)
BATTERY POWER SUPPLY
BLK WIRE
BLU WIRE
BRN WIRE
DATA LINK CONNECTOR
DIAGNOSTIC CAN COMM H
DIAGNOSTIC CAN COMM L
FUSE 39
FUSE 7
FUSE 8
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGNITION POWER SUPPLY
IT CAN COMM H
IT CAN COMM L
ITS CAN-H
ITS CAN-L
K LINE
LEFT "C" PILLAR)
LEFT SIDE RADAR
LT BLU WIRE
M CAN-H
M CAN-L
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
PNK WIRE
PPL
PPL/BLU WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RIGHT SIDE RADAR
SHIELD
TAN WIRE
VEHICLE CAN COMM 1 H
VEHICLE CAN COMM 1 L
W/O BLIND SPOT WARNING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, w/o propilot assist (1 of 4) -> W/O BLIND SPOT WARNING SYSTEM
