Nissan Altima L34 (2018-2024) rir sensor Wiring diagram
This page shows the only wiring diagram for the component.rir sensor, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rir sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PPL/PNK CAN-L WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 40
FUSE 46
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY 1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT INNER REAR SONAR SENSOR
LEFT OUTER REAR SONAR SENSOR
LT BLU WIRE
PNK WIRE
PPL
PPL RIR SENSOR SIGNAL
PPL/BLU WIRE
PPL/BRN WIRE
PPL/PNK WIRE
PWR
R RANGE SW
RED WIRE
RIGHT INNER REAR SONAR SENSOR
RIGHT OUTER REAR SONAR SENSOR
RIL SENSOR
RIL SENSOR SIGNAL
RIR SENSOR
ROL SENSOR
ROL SENSOR SIGNAL
ROR SENSOR
ROR SENSOR SIGNAL
RR SENSOR
RR SENSOR GND
RR SENSOR PWR
SIGNAL
SONAR BUZZER
SONAR CONTROL UNIT (LEFT CENTER OF DASH)
SPEAKER FR SIGNAL
SPEAKER PWR
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
TRANSMISSION RANGE SWITCH
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Sonar circuit -> RIR SENSOR
