Nissan Altima L34 (2018-2024) left map lamp switch Wiring diagram
This page shows the only wiring diagram for the component.left map lamp switch, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left map lamp switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
DOOR
FRONT ROOM/MAP LAMP ASSEMBLY
GRN WIRE
GRY WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR SWITCH (ALL)
INTERIOR SWITCH (DOOR)
LEFT MAP LAMP SWITCH
LEFT PERSONAL LAMP
LEFT VANITY MIRROR LAMP
LOCK
LOCK UNLOCK
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
OFF
OFF RIGHT MAP LAMP SWITCH
PNK WIRE
PPL/BRN WIRE
PPL/PNK WIRE
REAR PERSONAL LAMP
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SWITCH
RIGHT PERSONAL LAMP
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
RIGHT REAR DOOR SWITCH
RIGHT VANITY MIRROR LAMP
TAN WIRE
UNLOCK
UNLOCK LOCK
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT MAP LAMP SWITCH
