Nissan Altima L34 (2018-2024) left front speaker shield Wiring diagram
This page shows the only wiring diagram for the component.left front speaker shield, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front speaker shield (1 of 1)
2.0L TURBO
2.5L
ACTIVE GRILLE SHUTTER
ACTIVE NOISE CONTROL UNIT
BLK WIRE
BOSE SPEAKER AMP
COOLING FAN CONTROL MODULE 1
COOLING FAN CONTROL MODULE 2
COOLING FAN MOTOR 2
COOLING FAN RELAY 2
COOLING FAN RELAY 3
DISTANCE SENSOR
GRY WIRE
HOOD SWITCH
HORN (LOW)
LEFT FRONT COMBINATION LAMP (LOWER)
LEFT FRONT COMBINATION LAMP (UPPER)
LEFT FRONT DOOR SPEAKER SHIELD
LEFT FRONT FOG LAMP
LEFT FRONT SPEAKER SHIELD
LEFT REAR SPEAKER SHIELD
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
PPL/GRY WIRE
RIGHT FRONT COMBINATION LAMP (LOWER)
RIGHT FRONT COMBINATION LAMP (UPPER)
RIGHT FRONT DOOR SPEAKER SHIELD
RIGHT FRONT FOG LAMP
RIGHT FRONT SPEAKER SHIELD
RIGHT POWER SEAT SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SPEAKER SHIELD
SHIELD
W/ FRONT PASSENGER POWER SEAT
W/ HALOGEN HEADLAMPS
W/ LED HEADLAMPS
W/O BOSE AUDIO SYSTEM
WASHER FLUID LEVEL SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (2 of 5) -> LEFT FRONT SPEAKER SHIELD
