Nissan Altima L34 (2018-2024) its comm-h wiring diagram
This page shows the only wiring diagram for the component.its comm-h, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
its comm-h wiring diagram (1 of 1)
ACCEL/ RES SWITCH
ADAS CONTROL UNIT (W/ PROPILOT ASSIST) (RIGHT END OF DASH)
ADAS CONTROL UNIT (W/O PROPILOT ASSIST)
ASCD STEERING SWITCH
BLK WIRE
BLU WIRE
CAN L
CAN-H
CANCEL SWITCH
CHAS COMM
CHAS COMM-H
CHAS COMM-L
COAST/ SET SWITCH
COAST/ SET SWITCH DISTANCE SWITCH
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF SWITCH (MAIN SWITCH)
CRUISE ON/OFF SWITCH (MAIN SWITCH) CANCEL SWITCH
DISTANCE SENSOR (ICC SENSOR)
DRIVE
DRIVE SIG
DRV SIG
DRV SIG GND
FUSE 36
FUSE BLOCK (J/B)
GRN WIRE
GROUND
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
ICC STEERING SWITCH
IGN
IGNITION
ITS COMM
ITS COMM LO
ITS COMM-H
ITS COMM-L
LT BLU WIRE
MTR GND
MTR SIG (-)
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/PNK CAN-L WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/YEL WIRE
RED WIRE
STEERING VIBRATION MOTOR
STG ASST SW
TAN WIRE
W/ INTELLIGENT CRUISE CONTROL SYSTEM
W/ PROPILOT ASSIST
W/O INTELLIGENT CRUISE CONTROL SYSTEM
WARNING SYSTEM BUZZER
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 3) -> ITS COMM-H
