Nissan Altima L34 (2018-2024) its can-l right/left switching signal gnd Wiring diagram
This page shows the only wiring diagram for the component.its can-l right/left switching signal gnd, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram its can-l right/left switching signal gnd (1 of 1)
ADAS CONTROL UNIT (RIGHT END OF DASH)
BLIND SPOT WARNING SIGNAL CAN-L
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PNK ITS CAN-H WIRE
CAN-H UNIFIED METER CONTROL CAN-L UNIT (W/ INFORMATION DISPLAY)
CHASSIS CAN-H CHASSIS CAN-L WARNING SYSTEM BUZZER DRIVE SIGNAL
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
FUSE 36
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ILL
ITS CAN-H
ITS CAN-L
ITS CAN-L RIGHT/LEFT SWITCHING SIGNAL GND
LANE CAMERA UNIT
LDP SW
LEFT "C" PILLAR)
LEFT BLIND SPOT WARNING INDICATOR
LEFT SIDE RADAR
LT BLU WIRE
PNK WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT BLIND SPOT WARNING INDICATOR
RIGHT SIDE RADAR
STEERING ASSIST SWITCH
STEERING VIBRATION MOTOR
STEERING VIBRATION MOTOR GROUND
TAN WIRE
WARNING SYSTEM BUZZER
WARNING SYSTEM BUZZER DRIVE SIGNAL GROUND IGN STEERING VIBRATION MOTOR SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Driver assistance system circuit, w/ propilot assist -> ITS CAN-L RIGHT/LEFT SWITCHING SIGNAL GND
