Nissan Altima L34 (2018-2024) its can-l right/left switching sig gnd wiring diagram
This page shows the only wiring diagram for the component.its can-l right/left switching sig gnd, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
its can-l right/left switching sig gnd wiring diagram (1 of 1)
ADAS CONTROL UNIT
BLIND SPOT WARNING SIGNAL CAN-L
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PNK ITS CAN-H WIRE
CAN-H UNIFIED METER CONTROL CAN-L UNIT (W/ INFORMATION DISPLAY)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE BUZZER
FUSE 36
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ITS CAN-H
ITS CAN-L
ITS CAN-L RIGHT/LEFT SWITCHING SIG GND
LEFT "C" PILLAR)
LEFT BLIND SPOT WARNING INDICATOR
LEFT SIDE RADAR
LT BLU WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT BLIND SPOT WARNING INDICATOR
RIGHT SIDE RADAR
WARNING SYSTEM BUZZER DRIVE
WARNING SYSTEM BUZZER DRIVE SIGNAL
Go to component -> Driver assistance system circuit, w/o propilot assist -> ITS CAN-L RIGHT/LEFT SWITCHING SIG GND
