Nissan Altima L34 (2018-2024) camera on Wiring diagram
This page shows the only wiring diagram for the component.camera on, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera on (1 of 1)
AV CONTROL UNIT (W/ NAVIGATION) AUDIO UNIT (W/O NAVIGATION)
BLK WIRE
BLU WIRE
CAMERA
CAMERA COMP +
CAMERA GND
CAMERA ON
CAMERA SHIELD
CAMERA V +
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 23
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
PPL
PPL/GRN WIRE
REAR VIEW CAMERA
RED WIRE
SHIELD
W/ 7 INCH COLOR DISPLAY
W/ 8 INCH COLOR DISPLAY
WHT WIRE
YEL WIRE
Go to component -> Rear view camera circuit -> CAMERA ON
