Nissan Altima L34 (2018-2024) automatic brake hold switch indicator Wiring diagram
This page shows the only wiring diagram for the component.automatic brake hold switch indicator, which is found in the car Nissan Altima L34 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic brake hold switch indicator (1 of 1)
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SWITCH INDICATOR
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE SWITCH INDICATOR
ELECTRONIC SUSPENSION SYSTEM
FUSE 37
FUSE 6
FUSE 65
FUSE 7
FUSE 72
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ILL
LEFT PARKING BRAKE ACTUATOR
LT BLU WIRE
MRL+
MRR
PNK WIRE
PPL
PPL/BLU WIRE
PPL/PNK WIRE
RED WIRE
RIGHT PARKING BRAKE ACTUATOR
SW IND
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Electric parking brake circuit -> AUTOMATIC BRAKE HOLD SWITCH INDICATOR
