Nissan Altima L33 facelift (2015-2018) vent ctrl vlv Wiring diagram
This page shows the only wiring diagram for the component.vent ctrl vlv, which is found in the car Nissan Altima L33 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vent ctrl vlv (1 of 1)
ACC PEDAL POST SENS 1
ACCELERATOR PEDAL POSITION (APP) SENSOR
ACCL PDL SENS 2
AIR CONDITIONING SYSTEM
ASCD STRG SW
BLK WIRE
BLU WIRE
BRK PDL POST SENS
BRN WIRE
CALIFORNIA EXCEPT CALIFORNIA
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
CTRL SOL VLV
ECM (NEAR BATTERY)
ECM GND
ENGINE OIL PRSS
EVAP CONTROL SYSTEM PRESSURE SENSOR
FUEL TANK TEMP SENS
GRN WIRE
GRY WIRE
IGN SW
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PNP SIG
PPL
PRESS SENS
PWR SPLY
RED WIRE
REFRG PRSS SENS
SENS GND
SENS PWR SPLY
SENSOR 1
SENSOR 2
SHIELD
SNSR GND
STP LP SW
TAN WIRE
TRANSMISSION RANGE SWITCH
VENT CTRL VLV
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l (4 of 6) -> VENT CTRL VLV
