Nissan Altima L33 facelift (2015-2018) left front step lamp Wiring diagram
This page shows the only wiring diagram for the component.left front step lamp, which is found in the car Nissan Altima L33 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front step lamp (1 of 1)
BETWEEN FULL STROKE, N
BLK WIRE
BLK/WHT WIRE
FULL STROKE
GRN WIRE
KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT STEP LAMP
LOCK
LOCK SWITCH
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT STEP LAMP
RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH
TAN WIRE
TRUNK ROOM LAMP
UN LOCK
UNLOCK
UNLOCK SWITCH
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT FRONT STEP LAMP
