Nissan Altima L33 facelift (2015-2018) led daytime, parking lamp control module Wiring diagram
This page shows the only wiring diagram for the component.led daytime, parking lamp control module, which is found in the car Nissan Altima L33 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram led daytime, parking lamp control module (1 of 1)
3.5L 2.5L CALIFORNIA 2.5L EXCEPT CALIFORNIA
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ABS/TCS/VDC CONTROL UNIT
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLS
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE)
FUSE 51
FUSE 52
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED DAYTIME, PARKING LAMP CONTROL MODULE
LEFT FRONT COMBINATION LAMP
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
PARKING
PNK WIRE
PPL
RIGHT DOOR MIRROR
RIGHT END OF DASH)
RIGHT FRONT COMBINATION LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
STOP
STOP LP SW
TAIL
TAIL LAMP RELAY
TURN SIGNAL
VDC RESISTOR
W/ INTELLIGENT CRUISE CONTROL SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LED DAYTIME, PARKING LAMP CONTROL MODULE
