Nissan Altima L33 facelift (2015-2018) can-h pnk combi sw out 2 Wiring diagram
This page shows the only wiring diagram for the component.can-h pnk combi sw out 2, which is found in the car Nissan Altima L33 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can-h pnk combi sw out 2 (1 of 1)
AS DOOR SW
BAT BCM FUSE
BAT PWR (F/L)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRAKE SW LAMP
BRN WIRE
BUZZER
CAN-H PNK COMBI SW OUT 2 WIRE
COMBI SW IN 2 PNK COMBI SW IN 1 WIRE
COMBI SW IN 3
COMBI SW IN 4
COMBI SW IN 5
COMBI SW OUT 1
COMBI SW OUT 3
COMBI SW OUT 4
COMBI SW OUT 5
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
DR DOOR SW
FL FLASHER
FR FLASHER
FUSE 1
FUSE 10
FUSE 13
FUSE 31
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK I
GRN WIRE
GRY WIRE
HAZARD SW
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
LEFT DOOR MIRROR
LEFT LICENSE PLATE LAMP
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
PNK CAN-L WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
RIGHT LICENSE PLATE LAMP
RIGHT TURN IND
RL DOOR SW PPL RR DOOR SW
RL FLASHER
RR FLASHER
SIDE LIGHT, HEADLIGHT IND
STOP LAMP RELAY
STOP LAMP SWITCH
TAN WIRE
UNIFIED METER CONTROL UNIT
W/ REAR SPOILER
W/O REAR SPOILER
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> CAN-H PNK COMBI SW OUT 2 WIRE
