Nissan Altima L33 facelift (2015-2018) abs/tcs/vdc control unit Wiring diagrams
This page contains all the electrical diagrams for the component. abs/tcs/vdc control unit, in which he is found in the car Nissan Altima L33 facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
abs/tcs/vdc control unit wiring diagram (1 of 3)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ABS/TCS/VDC CONTROL UNIT
ACTUATOR
BLK WIRE
BLS
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FL IN
FL OUT
FL WSP
FL WSS
FR IN
FR OUT
FR WSP
FR WSS
FUSE 10
FUSE 31
FUSE 49
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK G
FUSIBLE LINK H
GND (ECU)
GND EXT
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HSV 1
HSV 2
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT BLU WIRE
LT GRN WIRE
MOTOR
MOTOR RELAY
PNK WIRE
PPL
RED WIRE
RELAY UNIT
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL IN
RL OUT
RL WSP
RR IN
RR OUT
RR WSP
RR WSS
SHIELD
SOLENOID VALVE RELAY
VAC
VDC OFF
VDC OFF SWITCH
VDC RESISTER
W/ INTELLIGENT CRUISE CONTROL SYSTEM
W/O INTELLIGENT CRUISE CONTROL SYSTEM W/ INTELLIGENT CRUISE CONTROL SYSTEM
WAU
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> ABS/TCS/VDC CONTROL UNIT
abs/tcs/vdc control unit wiring diagram (2 of 3)
A/C AUTO AMPLIFIER (BEHIND A/C SWITCH ASSEMBLY)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ABS/TCS/VDC CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT
AUDIO UNIT
AUTOMATIC A/C
AV CONTROL UNIT (W/ NAVIGATION)
BCM (BODY CONTROL MODULE) (BEHIND INSTRUMENT CLUSTER)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER
CPU IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
DATA LINK CONNECTOR
ECM (NEAR BATTERY)
FRONT AIR CONTROL
FUSE 1
FUSE 29
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MANUAL A/C
PNK CAN-L WIRE
PNK WIRE
POWER STEERING CONTROL MODULE
RED WIRE
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
Go to component -> Computer data lines circuit (1 of 2) -> ABS/TCS/VDC CONTROL UNIT
abs/tcs/vdc control unit wiring diagram (3 of 3)
3.5L 2.5L CALIFORNIA 2.5L EXCEPT CALIFORNIA
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ABS/TCS/VDC CONTROL UNIT
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLS
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE)
FUSE 51
FUSE 52
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED DAYTIME, PARKING LAMP CONTROL MODULE
LEFT FRONT COMBINATION LAMP
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
PARKING
PNK WIRE
PPL
RIGHT DOOR MIRROR
RIGHT END OF DASH)
RIGHT FRONT COMBINATION LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
STOP
STOP LP SW
TAIL
TAIL LAMP RELAY
TURN SIGNAL
VDC RESISTOR
W/ INTELLIGENT CRUISE CONTROL SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> ABS/TCS/VDC CONTROL UNIT
