Nissan Altima L33 (2012-2015) shield 2 1 Wiring diagrams
This page contains all the electrical diagrams for the component. shield 2 1, in which he is found in the car Nissan Altima L33 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shield 2 1 (1 of 2)
18 19 PPL
ACCELERATOR PEDAL POSITION (APP) SENSOR (ON ACCELERATOR PEDAL ASSEMBLY)
ASCDSW FTPRES
BATT CVTC 1 PNK WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
ECM (LEFT FRONT OF ENGINE COMPT)
ENG TACH
FUEL LEVEL SENSOR
FUEL LEVEL SENSOR UNIT, FUEL PUMP (IN FUEL TANK)
FUEL PUMP
FUEL TANK TEMPERATURE SENSOR
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GND-PHASE 1 POS
GND-POS
GNDA-ASCDSW IGNSW TACHO (CABIN) TF GNDA-FTPRES CAN-L CAN-H
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE 7
INSTRUMENT CLUSTER SYSTEM
KLINE
LT BLU WIRE
LT GRN WIRE
NEUT-H
ORG/ WIRE
PHASE 1
PNK PPL GNDA-TF VBR BRAKE GND GND CDCV BNCSW GND GND WIRE
PNK WIRE
POWER STEERING CONTROL UNIT (RIGHT FRONT OF ENGINE COMPT)
PPL
PPL/WHT WIRE
RED WIRE
SENSOR 1
SENSOR 2
SHIELD
SHIELD 2 1
STOP LAMP RELAY 1 (IN FUSE, FUSIBLE LINK BOX)
W/ REARVIEW MONITOR
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l, coupe california (4 of 4) -> SHIELD 2 1
Wiring diagram shield 2 1 (2 of 2)
