Nissan Altima L33 (2012-2015) left front outside handle Wiring diagram
This page shows the only wiring diagram for the component.left front outside handle, which is found in the car Nissan Altima L33 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front outside handle (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR (IF EQUIPPED) (BASE OF SHIFTER ASSEMBLY)
FRONT CONSOLE ANTENNA (REAR OF CENTER CONSOLE)
FUSE 46
GRN WIRE
HEADLIGHTS SYSTEM
HORNS SYSTEM
HOT AT ALL TIMES
IGNITION RELAY 1
IPDM E/R (INTELLIGENT
J/C
LEFT FRONT OUTSIDE HANDLE
LT BLU WIRE
LT GRN WIRE
OUTSIDE KEY REQUEST ANTENNA SWITCH (IF EQUIPPED)
PARK POSITION SWITCH
PNK PNK WIRE
PNK PPL WIRE
PNK WIRE
POWER DISTRIBUTION MODULE ENGINE ROOM) (LEFT SIDE OF ENGINE COMPT)
PPL
PPL 28 29
RED WIRE
RIGHT FRONT OUTSIDE HANDLE
STARTER CONTROL RELAY
STARTER RELAY
STARTING/ CHARGING SYSTEM
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, sedan (2 of 4) -> LEFT FRONT OUTSIDE HANDLE
