Nissan Altima L33 (2012-2015) encoder power encoder gnd Wiring diagram

1 10 BAT IGN PPL 11 13 BAT BCM FUSE 12 8 11 13 9 5 14 COM AS UP AS DOWN 58 32 40 DR DOOR SWITCH AS DOOR SWITCH PW K-LINE 7 6 UNLOCK LOCK BAT POWER F/L BCM (BODY CONTROL MODULE) (BEHIND LEFT SIDE OF DASH) BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COM BATT GND GND 16 10 11 3 12 15 4 9 PNK WIRE ENCODER ENCODER POWER ENCODER GND FULL STROKE FUSE 10 (BEHIND LEFT END OF DASH) FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEAR IPDM E/R) FUSIBLE LINK H GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) BETWEEN FULL STROKE, N LEFT DOOR SWITCH LEFT POWER WINDOW MOTOR LOCK LOCK SWITCH CPU LOCK SWITCH LOCK SWITCH LOCK LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH POWER DOWN POWER WINDOW- POWER SUPPLY P/W POWER SUPPLY PERM 3 2 RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT DOOR SWITCH RIGHT POWER WINDOW MOTOR RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH UNLOCK UNLOCK SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
