Nissan Altima L33 (2012-2015) data link connector (left side Wiring diagram
This page shows the only wiring diagram for the component.data link connector (left side, which is found in the car Nissan Altima L33 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data link connector (left side (1 of 1)
1 2 3 VCC GND SIG
ACU COMM
AIR BAG IND
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION METER
DATA LINK CONNECTOR (LEFT SIDE
FRONT INNER GND FRONT INNER SIG GND
FRONT INNER VCC REAR INNER SIG REAR INNER GND
FUSE 13
FUSE 31
FUSE 32
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
J/C
K LINE
LEFT "C" PILLAR)
LEFT REAR OCCUPANT CLASSIFICATION SYSTEM SENSOR
LT BLU WIRE
LT GRN WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT
OF DASH)
ORG/ WIRE
PNK WIRE
PPL
REAR INNER VCC
RED WIRE
RED/BLK WIRE
SEAT BELT IND
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, sedan (3 of 3) -> DATA LINK CONNECTOR (LEFT SIDE
