Nissan Altima L32 facelift (2009-2013) usb interface Wiring diagrams
This page contains all the electrical diagrams for the component. usb interface, in which he is found in the car Nissan Altima L32 facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram usb interface (1 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
2.5L CVT
21 22 23 24 USB GND USB D- V BUS USB D+
3.5L, CVT
5 6 PPL PPL
ANTENNA AMPLIFIER
AV CONTROL UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EXCEPT 3.5L CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
JOINT
M/T
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SATELLITE ANTENNA
SHIELD
SIG
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Bose radio circuit, coupe with navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (2 of 9)
2.5L M/T CVT
3.5L EXCEPT CVT 3.5L CVT
70 71 72 73 74 75 76 SHIELD
77 78 79 80 USB GND USB D- V BUS USB D+
81 82 83 AMP SUPPLY MAIN ANTENNA
ANTENNA AMPLIFIER
ANTENNA SIG
AUDIO UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CAMERA ON
COMP+
DATA
EARTH (SIG)
EXCEPT 3.5L 3.5L CVT CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/WHT WIRE
HOT IN ON OR START
JOINT
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PPL PPL 5 6
REAR VIEW CAMERA (LEFT REAR BODY)
RED WIRE
RED/WHT WIRE
REQ (SAT-COMBI) RX (SAT-COMBI) TX (COMBI-SAT)
REVERSE SGN
RXD
SAT LCH (+)
SAT RCH (-)
SATELLITE ANTENNA
SHIELD
SHIELD SHIELD
TEL GND TEL ON
TXD
USB GND
USB INTERFACE
USB(D-)
V-BUS
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDOW ANTENNA
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Bose radio circuit, coupe without navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (3 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
2.5L CVT
21 22 23 24 USB GND USB D- V BUS USB D+
3.5L, CVT
5 6 PPL
ANTENNA AMPLIFIER
AV CONTROL UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CVT
EXCEPT 3.5L CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
JOINT
M/T
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SATELLITE ANTENNA
SHIELD
SIG
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Bose radio circuit, sedan, except hybrid with navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (4 of 9)
2.5L M/T CVT
27 28 29 30 GND MCAN A+ MCAN A- MCAN SHIELD
3.5L EXCEPT CVT 3.5L CVT PPL
5 6 PPL
77 78 79 80 USB GND USB D- V BUS USB D+
81 82 83 AMP SUPPLY MAIN ANTENNA
ANTENNA AMPLIFIER
ANTENNA SIG
AUDIO UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAMERA ON
COMP+
EXCEPT 3.5L 3.5L CVT CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/WHT WIRE
HOT IN ON OR START
JOINT
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK/BLK WIRE
REAR VIEW CAMERA (LEFT REAR BODY)
RED WIRE
RED/WHT WIRE
REQ (SAT-COMBI) RX (SAT-COMBI) TX (COMBI-SAT)
REVERSE SGN
RXD
SAT LCH (+)
SAT RCH (-)
SATELLITE ANTENNA
SHIELD
SHIELD SHIELD
TEL GND TEL ON
TEL I/F + TEL I/F - TEL SHIELD
TXD
USB D-
USB GND
USB INTERFACE
V-BUS
WHT WIRE
WHT/RED WIRE
WINDOW ANTENNA
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Bose radio circuit, sedan, except hybrid without navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (5 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
21 22 23 24 USB GND USB D- V BUS USB D+
AUX AUDIO LH+
AV CONTROL UNIT (CENTER OF DASH)
BACKUP LAMP RELAY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
JOINT
JUNCTION BLOCK
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOF ANTENNA (AUDIO)
ROOF ANTENNA (SATELLITE)
SHIELD
SHIELD AUX SHIELD AUX AUDIO RH AUX AUDIO -
SHIELD SHIELD
SIG
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Bose radio circuit, sedan, hybrid with navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (6 of 9)
70 71 72 73 74 75 76 SHIELD
77 78 79 80 USB GND USB D- V BUS USB D+
81 82 83 AMP SUPPLY MAIN ANTENNA
ANTENNA SIG
AUDIO UNIT
BACKUP LAMP RELAY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CAMERA ON
COMP+
DATA EARTH
EARTH (SIG)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
JOINT
LT BLU WIRE
PNK/BLK WIRE
PPL
PPL/YEL WIRE
REAR VIEW CAMERA
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
REQ (SAT-COMBI) RX (SAT-COMBI) TX (COMBI-SAT)
REVERSE SGN
ROOF ANTENNA (AUDIO)
ROOF ANTENNA (SATELLITE)
RXD
SAT LCH (+)
SAT RCH (-)
SHIELD
SHIELD 5 6 7
SHIELD SHIELD
SHIELD SHIELD SHIELD
TEL GND TEL ON
TEL I/F + TEL I/F - TEL SHIELD
TXD
USB D-
USB GND
USB INTERFACE
V-BUS
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDOW ANTENNA
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Bose radio circuit, sedan, hybrid without navigation (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (7 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
2.5L CVT
21 22 23 24 USB GND USB D- V BUS USB D+
3.5L, CVT
5 6 PPL PPL
ANTENNA AMPLIFIER
AV CONTROL UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EXCEPT 3.5L CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
JOINT
M/T
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SATELLITE ANTENNA
SHIELD
SIG
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Navigation circuit, coupe (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (8 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
2.5L CVT
21 22 23 24 USB GND USB D- V BUS USB D+
3.5L, CVT
5 6 PPL
ANTENNA AMPLIFIER
AV CONTROL UNIT
BACKUP LAMP SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CVT
EXCEPT 3.5L CVT
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
JOINT
M/T
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SATELLITE ANTENNA
SHIELD
SIG
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Navigation circuit, sedan except hybrid (3 of 3) -> USB INTERFACE
Wiring diagram usb interface (9 of 9)
107 108 109 AMP SUPPLY MAIN ANTENNA
21 22 23 24 USB GND USB D- V BUS USB D+
AUX AUDIO LH+
AV CONTROL UNIT (CENTER OF DASH)
BACKUP LAMP RELAY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
GPS ANTENNA
GRN WIRE
GRN/RED WIRE
JOINT
JUNCTION BLOCK
MIC GND MIC +B
MIC SIG
MICROPHONE
MR OUTPUT IGN REVERSE SIG SPEED
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PKB SIG
PNK CAN-L WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOF ANTENNA (AUDIO)
ROOF ANTENNA (SATELLITE)
SHIELD
SHIELD AUX SHIELD AUX AUDIO RH AUX AUDIO -
SHIELD SHIELD
SIG
USB D-
USB GND
USB INTERFACE
V-BUS
VCC
WHT WIRE
WINDOW ANTENNA
Go to component -> Navigation circuit, sedan hybrid (3 of 3) -> USB INTERFACE
