Nissan Altima L32 facelift (2009-2013) source seek up Wiring diagram

36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 PNK WIRE 75 76 77 AMP POWER SUPPLY MAIN ANTENNA ANTENNA AMPLIFIER ANTENNA SIGNAL AUDIO UNIT BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE FR SP LH (+) FR SP LH (-) RR SP LH (+) RR SP LH (-) STRG SW A FR SP RH (+) FR SP RH (-) RR SP RH (+) RR SP RH (-) STRG SW GND STRG SW B FUSE 19 FUSE 24 LINK BOX (LEFT FRONT OF ENGINE COMPT, NEAR IPDM E/R) FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSIBLE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON OR ACC ILL CONT OUT TAIL/ILL RLY LEFT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL PPL/YEL WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR SPEAKER RX (SAT TO COMBI) TX (COMBI TO SAT) RXD (COMBI-SAT) TXD (SAT-COMBI) SAT RCH (+) SAT RCH (-) SAT LCH (+) SAT LCH (-) SATELLITE ANTENNA SATELLITE RADIO TUNER (IF EQUIPPED) (UNDER REAR PARCEL SHELF) SEEK DOWN SOURCE SEEK UP SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN) STEERING WHEEL AUDIO CONTROL SWITCHES (IF EQUIPPED) VOL DOWN VOL UP WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WINDOW ANTENNA SHIELD YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
