Nissan Altima L32 facelift (2009-2013) r camera comp Wiring diagrams
This page contains all the electrical diagrams for the component. r camera comp, in which he is found in the car Nissan Altima L32 facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
r camera comp wiring diagram (1 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
AUX AUDIO
AUX AUDIO LH+
AUX AUDIO RH+
AUX JACK
AUX SHIELD
AUX VIDEO -
AV CONTROL UNIT
BACK
BACKUP LAMP RELAY (NEAR FUSE BLOCK BOX (J/B))
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
JUNCTION BLOCK
LT GRN WIRE
MENU
ORG/ WIRE
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
TRANSMISSION REV CONTROL LAMP MODULE (TCM) RLY (LEFT FRONT OF ENGINE COMPT)
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Bose radio circuit, coupe with navigation (2 of 3) -> R CAMERA COMP
r camera comp wiring diagram (2 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON
AUX AUDIO
AUX AUDIO LH+
AUX AUDIO RH+
AUX JACK
AUX SHIELD
AUX VIDEO -
AV CONTROL UNIT
BACK
BACKUP LAMP RELAY (NEAR FUSE BLOCK BOX (J/B))
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
JUNCTION BLOCK
LT GRN WIRE
MENU
ORG/ WIRE
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
RED WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
TRANSMISSION REV CONTROL LAMP MODULE (TCM) RLY (LEFT FRONT OF ENGINE COMPT)
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Bose radio circuit, sedan, except hybrid with navigation (2 of 3) -> R CAMERA COMP
r camera comp wiring diagram (3 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON
AUX JACK
AUX VIDEO -
AV CONTROL UNIT (CENTER OF DASH)
BACK
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
MENU
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
REAR VIEW CAMERA
RED/BLK WIRE
RED/BLU WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Bose radio circuit, sedan, hybrid with navigation (2 of 3) -> R CAMERA COMP
r camera comp wiring diagram (4 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
AUX AUDIO
AUX AUDIO LH+
AUX AUDIO RH+
AUX JACK
AUX SHIELD
AUX VIDEO -
AV CONTROL UNIT
BACK
BACKUP LAMP RELAY (NEAR FUSE BLOCK BOX (J/B))
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
JUNCTION BLOCK
LT GRN WIRE
MENU
ORG/ WIRE
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
TRANSMISSION REV CONTROL LAMP MODULE (TCM) RLY (LEFT FRONT OF ENGINE COMPT)
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Navigation circuit, coupe (2 of 3) -> R CAMERA COMP
r camera comp wiring diagram (5 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON
AUX AUDIO
AUX AUDIO LH+
AUX AUDIO RH+
AUX JACK
AUX SHIELD
AUX VIDEO -
AV CONTROL UNIT
BACK
BACKUP LAMP RELAY (NEAR FUSE BLOCK BOX (J/B))
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
JUNCTION BLOCK
LT GRN WIRE
MENU
ORG/ WIRE
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
RED WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
TRANSMISSION REV CONTROL LAMP MODULE (TCM) RLY (LEFT FRONT OF ENGINE COMPT)
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Navigation circuit, sedan except hybrid (2 of 3) -> R CAMERA COMP
r camera comp wiring diagram (6 of 6)
2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO -
4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON
AUX JACK
AUX VIDEO -
AV CONTROL UNIT (CENTER OF DASH)
BACK
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMERA GND
CAMERA V +
DOWN
ENTER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR
MENU
PHONE
PNK WIRE
R CAMERA COMP
R CAMERA SHIELD
REAR VIEW CAMERA
RED/BLK WIRE
RED/BLU WIRE
SHIELD
SOURCE
SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN)
STEERING WHEEL AUDIO CONTROL SWITCHES
VIDEO SHIELD
VOL (-)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Navigation circuit, sedan hybrid (2 of 3) -> R CAMERA COMP
