Nissan Altima L32 facelift (2009-2013) l/u, select- on/off sol l/u&select-liner sol sec liner sol pl liner sol Wiring diagram

3 2 1 VIGN SENS SPD SENS GND PPL 98 97 CAN-H CAN-L A/T CHECK ATF TEMP SENS PRI OIL PRESS SENS SEC OIL PRESS SENS BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM PNK PRIMARY PRESSURE SENSOR WIRE COMPUTER DATA LINES SYSTEM PNK WIRE CVT FLUID TEMPERATURE SENSOR CVT SHIFT SELECTOR CVT UNIT (LEFT SIDE OF TRANSMISSION) DOWN SW ECM (LEFT FRONT OF ENGINE COMPT) EXTERIOR LIGHTS SYSTEM BACKUP LMP RLY STARTER RLY FUSE 11 FUSE 4 FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN CAN-H CAN-L AT SHIFT UP AT SHIFT DN M RANGE NOT M RANGE 21 22 39 38 40 37 L/U, SELECT- ON/OFF SOL L/U&SELECT-LINER SOL SEC LINER SOL PL LINER SOL LINE PRESSURE SOLENOID VALVE LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE MODE SELECT SW ORG/ WIRE PNK PNK WIRE PNK WIRE PPL PPL P RANGE SW PRIMARY SPEED SENSOR RED WIRE ROM ASSEMBLY SECONDARY PRESSURE SENSOR SECONDARY PRESSURE SOLENOID VALVE SECONDARY SPEED SENSOR (ON TRANSAXLE) SENSOR GND STARTING/ CHARGING SYSTEM STEP MOTOR TCM (LEFT FRONT OF ENGINE COMPT) TORQUE LOCK-UP CONVERTER SELECT CLUTCH SOLENOID SOLENOID VALVE VALVE TRANSMISSION RANGE SWITCH UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) UP SW VIGN BATT VIGN PPL WHT WIRE YEL WIRE
