Nissan Altima L32 facelift (2009-2013) left front combination lamp turn sig Wiring diagram
This page shows the only wiring diagram for the component.left front combination lamp turn sig, which is found in the car Nissan Altima L32 facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front combination lamp turn sig (1 of 1)
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE FUSE
FUSIBLE LINK BOX (BATTERY) (AT BATTERY)
FUSIBLE LINK D
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN ON OR START
JOINT CONNECTOR
LEFT FRONT COMBINATION LAMP TURN SIG
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
M/T CVT
ORG/ WIRE
PARKING 10 11
PNK WIRE
RIGHT DOOR MIRROR (IF EQUIPPED) (IN MIRROR)
RIGHT FRONT COMBINATION LAMP PARKING 10 11
RIGHT REAR COMBINATION LAMP STOP
STOP
TAIL
TAIL 2 5
TAIL LAMP RELAY
TURN SIG
TURN SIG 5 7
W/ REAR VIEW MONITOR
W/O REAR VIEW MONITOR
WHT WIRE
Go to component -> Exterior lamps circuit, coupe (2 of 2) -> LEFT FRONT COMBINATION LAMP TURN SIG
