Nissan Altima L32 facelift (2009-2013) left end of dash) Wiring diagrams
This page contains all the electrical diagrams for the component. left end of dash), in which he is found in the car Nissan Altima L32 facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left end of dash) (1 of 2)
13 11 17 18 GND 1 BAT BCM FUSE FR FLASHER FL FLASHER
148 149 RR DOOR SW RL DOOR SW
2 21 22 23 COMPUTER DATA LINES PNK SYSTEM WIRE
54 53 52 51 50 INPUT 4 INPUT 3 INPUT 2 INPUT 1 INPUT 5
58 32 DR DOOR SW AS DOOR SW
BAT PWR (F/L)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
FUSE
FUSE BLOCK (J/B) (BEHIND
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEAR IPDM E/R)
FUSIBLE LINK H
GRN/BLK WIRE
GRN/ORG WIRE
GRN/YEL WIRE
GRY WIRE
HAZARD SW
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
JOINT CONNECTOR
LEFT DOOR MIRROR (IF EQUIPPED) (IN MIRROR)
LEFT END OF DASH)
LEFT LICENSE PLATE LAMP
LEFT TURN IND
LT BLU WIRE
LT GRN (OR YEL) WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
M/T CVT
ORG/ WIRE
PEDAL, ON BRACKET)
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT LICENSE PLATE LAMP
RIGHT TURN IND
STOP LAMP RELAY 1
STOP LAMP RELAY 2
STOP LIGHT SWITCH (ABOVE BRAKE
STOP LIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL BLK/ WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, coupe (1 of 2) -> LEFT END OF DASH)
Wiring diagram left end of dash) (2 of 2)
BATTERY CURRENT SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ECM (LEFT FRONT OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
FPR
FUEL INJECTORS (TOP OF ENGINE)
FUSE 4
FUSE BLOCK (J/B) (BEHIND
GNDA-CURSEN AF+1 TW
GNDA-PSPRES AF-1
GNDA-TW
GRN WIRE
GRY WIRE
HOT IN ON OR START
IGN 3 IGN 2 IGN 1 GND
IGN 4
INJ 4 INJ 3 INJ 2 INJ 1
IPDM E/R POWER
JOINT CONNECTOR
JUNCTION BLOCK
LEFT END OF DASH)
LT BLU (OR WHT/RED) WIRE
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
ORG/ WIRE
ORG/BLU WIRE
OUTPUT
PDPRES GNDA-PDRES PSPRES CURSEN
PNK WIRE
POWER STEERING PRESSURE SENSOR (ON POWER STEERING PUMP)
PPL
RED WIRE
RED/BLK WIRE
REFRIGERANT PRESSURE SENSOR (LEFT FRONT OF ENGINE COMPT)
SIG
SSOF EVAP PNK WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l, except california (1 of 4) -> LEFT END OF DASH)
