Nissan Altima L32 facelift (2009-2013) bat bcm fuse step lamp output room lamp bat saver room lamp output 7 4 19 Wiring diagram

130 148 149 TRUNK SW RR DOOR SW RL DOOR SW 32 58 AS DOOR SW DR DOOR SW 5 6 7 LIGHT BAT+ LIGHT A GND 80 79 78 FOB SLOT ILLUMINATION CAN-H CAN-L BAT BCM FUSE STEP LAMP OUTPUT ROOM LAMP BAT SAVER ROOM LAMP OUTPUT 7 4 19 BAT PWR (F/L) BLK WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM COUPE DOOR DOOR ON EXCEPT HYBRID FRONT ROOM/MAP LAMP ASSEMBLY FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE FUSE FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEAR IPDM E/R) FUSIBLE LINK J (HYBRID) FUSIBLE LINK H (EXCEPT HYBRID) GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES INTERIOR ROOM LAMP INTERIOR ROOM ON ON LAMP SWITCH OFF DOOR JOINT JOINT CONNECTOR KEY SLOT LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR) LEFT FRONT ROOM/MAP LAMP HYBRID LEFT REAR DOOR SWITCH (SEDAN) (AT LEFT "C" PILLAR) LEFT REAR PERSONAL LAMP LEFT STEP LAMP LEFT VANITY MIRROR LAMP LT BLU WIRE LT GRN WIRE OFF OFF ON OFF ON ON OFF DOOR PNK WIRE PNK/WHT WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR) RIGHT FRONT ROOM/MAP LAMP RIGHT REAR DOOR SWITCH (SEDAN) (AT RIGHT "C" PILLAR) RIGHT REAR PERSONAL LAMP RIGHT STEP LAMP RIGHT VANITY MIRROR LAMP SEDAN TRUNK LAMP OUTPUT TRUNK LAMP SWITCH, TRUNK RELEASE SOLENOID (REAR CENTER OF TRUNK LID) TRUNK ROOM LAMP WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
