Nissan Altima L32 facelift (2009-2013) 4 3 2 1 shield comp - comp + gnd camera on Wiring diagrams

This page contains all the electrical diagrams for the component. 4 3 2 1 shield comp - comp + gnd camera on, in which he is found in the car Nissan Altima L32 facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram 4 3 2 1 shield comp - comp + gnd camera on (1 of 4)

Wiring diagram 4 3 2 1 shield comp - comp + gnd camera on for Nissan Altima L32 facelift (2009-2013) (1 of 4)

Get access

2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO - 4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON AUX AUDIO AUX AUDIO LH+ AUX AUDIO RH+ AUX JACK AUX SHIELD AUX VIDEO - AV CONTROL UNIT BACK BACKUP LAMP RELAY (NEAR FUSE BLOCK BOX (J/B)) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAMERA GND CAMERA V + DOWN ENTER GRN WIRE GRY WIRE GRY/BLU WIRE JOINT CONNECTOR JUNCTION BLOCK LT GRN WIRE MENU ORG/ WIRE PHONE PNK WIRE R CAMERA COMP R CAMERA SHIELD RED WIRE SHIELD SOURCE SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN) STEERING WHEEL AUDIO CONTROL SWITCHES TRANSMISSION REV CONTROL LAMP MODULE (TCM) RLY (LEFT FRONT OF ENGINE COMPT) VIDEO SHIELD VOL (-) WHT WIRE WHT/GRN WIRE YEL WIRE

Go to component -> Bose radio circuit, sedan, except hybrid with navigation (2 of 3) -> 4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON

Wiring diagram 4 3 2 1 shield comp - comp + gnd camera on (2 of 4)

Wiring diagram 4 3 2 1 shield comp - comp + gnd camera on for Nissan Altima L32 facelift (2009-2013) (2 of 4)

Get access

2 1 3 7 8 AUX AUDIO - AUX AUDIO RH AUX AUDIO LH AUX VIDEO + AUX VIDEO - 4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON AUX JACK AUX VIDEO - AV CONTROL UNIT (CENTER OF DASH) BACK BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAMERA GND CAMERA V + DOWN ENTER GRN WIRE GRY WIRE GRY/BLU WIRE JOINT CONNECTOR MENU PHONE PNK WIRE R CAMERA COMP R CAMERA SHIELD REAR VIEW CAMERA RED/BLK WIRE RED/BLU WIRE SHIELD SOURCE SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN) STEERING WHEEL AUDIO CONTROL SWITCHES VIDEO SHIELD VOL (-) WHT WIRE WHT/GRN WIRE YEL WIRE

Go to component -> Bose radio circuit, sedan, hybrid with navigation (2 of 3) -> 4 3 2 1 SHIELD COMP - COMP + GND CAMERA ON
