Courtesy lamps circuit for Nissan Altima L32 (2006-2009)

130 148 149 TRUNK SW RR DOOR SW RL DOOR SW 32 58 AS DOOR SW DR DOOR SW 5 6 7 LIGHT BAT+ LIGHT A GND 80 79 78 FOB SLOT ILLUMINATION CAN-H CAN-L BAT BCM FUSE STEP LAMP OUTPUT ROOM LAMP BAT SAVER ROOM LAMP OUTPUT 7 4 19 BAT PWR (F/L) BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DOOR DOOR ON FRONT ROOM/MAP LAMP ASSEMBLY FUSE BLOCK (J/B) FUSE FUSE (BEHIND LEFT END OF DASH) GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES INTERIOR ROOM LAMP SWITCH ON JOINT CONNECTOR KEY SLOT LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR) LEFT FRONT ROOM/MAP LAMP LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR) LEFT REAR PERSONAL LAMP LEFT STEP LAMP LT BLU WIRE OFF OFF ON DOOR ON ON PNK WIRE PNK/WHT WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR) RIGHT FRONT ROOM/MAP LAMP RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR) RIGHT REAR PERSONAL LAMP RIGHT STEP LAMP RIGHT VANITY MIRROR LAMP LEFT VANITY MIRROR LAMP TRUNK LAMP OUTPUT TRUNK LAMP SWITCH, TRUNK RELEASE SOLENOID (REAR CENTER OF TRUNK LID) TRUNK ROOM LAMP WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
