Nissan Altima L31 facelift (2004-2006) sec ind out dr sw rr dr sw as key sw pwr win ser link can-h can-l Wiring diagram

14 6 DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) BAT BAT FUSE GND 57 67 BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) CAN (-) CAN (+) COM CPU HORN RELAY DOOR LOCK, UNLOCK SWITCH DR SW DR DR SW RL TRUNK KEY CYL TRUNK SW 48 41 42 FUSE 19 FUSE 21 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/ORG WIRE HEADLAMP HIGH RELAY HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON KEY SWITCH, KEY LOCK SOLENOID (ON RIGHT SIDE OF STEERING COLUMN) LEFT FRONT DOOR LOCK ASSEMBLY (KEY CYLINDER SWITCH) LEFT FRONT DOOR SWITCH LEFT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR SILL) LEFT REAR DOOR SWITCH (AT LEFT REAR DOOR SILL) LK SW LK UNLK LOCK-BETWEEN FULL STROKE, NORMAL UNLOCK-BETWEEN FULL STROKE, NORMAL LT BLU WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH ORG/ WIRE PNK WIRE PNK/BLU WIRE PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR DOOR SWITCH (AT RIGHT REAR DOOR SILL) SEC IND OUT DR SW RR DR SW AS KEY SW PWR WIN SER LINK CAN-H CAN-L SECURITY INDICATOR LAMP TAIL LAMP RELAY UNLK LK UNLK SW WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE
