Nissan Altima L31 facelift (2004-2006) right step lamp Wiring diagram
This page shows the only wiring diagram for the component.right step lamp, which is found in the car Nissan Altima L31 facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right step lamp (1 of 1)
1 37 13 12 39 40 KEY RING ILLUM OUT KEY SW DOOR SW (RR) DOOR SW (AS) CAN-H CAN-L
49 42 48 47 TRUNK LAMP OUTPUT TRUNK SW DOOR SW (RL) DOOR SW DR
56 62 BATTERY SAVER OUT STEP LAMP OUTPUT
70 67 BAT GND (PWR)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DOOR
FUSE 19
FUSE 21
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
FUSIBLE LINK F
HOT AT ALL TIMES
IGNITION KEYHOLE ILLUMINATION
KEY SWITCH, KEY LOCK SOLENOID (ON RIGHT SIDE OF STEERING COLUMN)
LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR SILL)
LEFT REAR DOOR SWITCH (AT LEFT REAR DOOR SILL)
LEFT STEP LAMP
LEFT VANITY MIRROR LAMP
LT BLU WIRE
OFF
OFF ON
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR SILL)
RIGHT REAR DOOR SWITCH (AT RIGHT REAR DOOR)
RIGHT STEP LAMP
RIGHT VANITY MIRROR LAMP
ROOM LAMP
ROOM LAMP OUTPUT
SILL)
SPOT LAMP
TRUNK LAMP SWITCH, TRUNK RELEASE SOLENOID (ON REAR CENTER OF TRUNK LID)
TRUNK ROOM LAMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit -> RIGHT STEP LAMP
