Nissan Altima L31 facelift (2004-2006) defogger system engine controls system Wiring diagram
This page shows the only wiring diagram for the component.defogger system engine controls system, which is found in the car Nissan Altima L31 facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defogger system engine controls system (1 of 1)
A/C RELAY
ANTI-THEFT, HORNS SYSTEMS COOLING FANS SYSTEM
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CPU CPU
DEFOGGER SYSTEM ENGINE CONTROLS SYSTEM
ECM RELAY
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, ANTI-THEFT SYSTEM HEADLIGHTS SYSTEM
ENGINE ROOM (IPDM E/R)
FROM FUSE 47 (DIAGRAM 2 OF 2)
FROM FUSE 48 (DIAGRAM 2 OF 2)
FRONT FOG LAMP RELAY
FRONT WIPER HI RELAY
FRONT WIPER RELAY
FUSE 25 FUSIBLE LINK H FUSE 26 FUSIBLE LINK K
FUSE 28 FUSIBLE LINK M
FUSE 29
FUSE 31
FUSE 33
FUSE 34
FUSE 35
FUSE 39
FUSE 43
FUSE 44 FUSE 41 FUSE 32 FUSE 37
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK BOX (BATTERY) (ON LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK G FUSIBLE LINK F
FUSIBLE LINK L
GRN WIRE
ORG/ WIRE
RED WIRE
SEATS SYSTEM TO IGNITION SWITCH (DIAGRAM 2 OF 2)
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
TAIL LAMP RELAY THROTTLE CONTROL MOTOR RELAY
TO FUSE 19 (DIAGRAM 2 OF 2)
TO HEADLIGHT HI RELAY (DIAGRAM 2 OF 2)
TO IGNITION RELAY
W/ ABS OR TCS
W/ FRONT FOG LAMPS
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> DEFOGGER SYSTEM ENGINE CONTROLS SYSTEM
