Nissan Altima L31 facelift (2004-2006) cpu fuse 45 fuse 36 Wiring diagram
This page shows the only wiring diagram for the component.cpu fuse 45 fuse 36, which is found in the car Nissan Altima L31 facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cpu fuse 45 fuse 36 (1 of 1)
ACCESSORY RELAY
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM WIPER/ WASHER SYSTEM ENGINE CONTROLS SYSTEM
ANTI-THEFT, ENGINE CONTROLS SYSTEMS
BLK WIRE
BLK/RED WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
CPU FUSE 45 FUSE 36
DEFOGGER SYSTEM
FROM FUSE 35 (DIAGRAM 1 OF 2)
FROM FUSE 43 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK C (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK M (DIAGRAM 1 OF 2)
FROM IGNITION SWITCH (DIAGRAM 2 OF 2)
FUEL PUMP RELAY
FUSE 11 FUSE 10
FUSE 12 FUSE 1
FUSE 13
FUSE 14
FUSE 17
FUSE 19
FUSE 20 FUSE 21
FUSE 38 FUSE 40
FUSE 42 FUSE 49 FUSE 47 FUSE 46
FUSE 50 FUSE 48
FUSE 6
FUSE 7 FUSE 5
FUSE 9 FUSE 8
GRN WIRE
GRY WIRE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
HEADLIGHTS SYSTEM
HEADLIGHTS, ANTI-THEFT SYSTEMS
IGNITION RELAY
IGNITION SWITCH
NAVIGATION SYSTEM
ON LOCK OFF
ORG/ WIRE
POWER SOCKET
PPL
RED WIRE
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO A/C RELAY (DIAGRAM 1 OF 2)
TO FRONT WIPER HI RELAY (DIAGRAM 1 OF 2)
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM ENGINE CONTROLS SYSTEM
TRANSMISSIONS, ANTI-LOCK BRAKES, ENGINE CONTROLS, EXTERIOR LIGHTS SYSTEMS
TRANSMISSIONS, ENGINE CONTROLS, STARTING/ CHARGING SYSTEMS
W/ ABS OR TCS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> CPU FUSE 45 FUSE 36
