Nissan Altima L31 facelift (2004-2006) auto light sensor (on upper Wiring diagrams
This page contains all the electrical diagrams for the component. auto light sensor (on upper, in which he is found in the car Nissan Altima L31 facelift (2004-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram auto light sensor (on upper (1 of 2)
3 2 1 PNK GND OUT POWER WIRE
6 5 2 1 14 15 H/L LH HI H/L LH HI FUSE ST SIG ALT GND RH HI
70 67 BAT GND
9 10 11 12 13 16 17 18 H/L RH HI GND H/L LH HI GND
AUTO LIGHT SENSOR (ON UPPER
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/YEL WIRE
COMBINATION METER
COMBINATION SWITCH (LIGHTING SWITCH)
DAYTIME LIGHT CONTROL UNIT (UNDER LEFT SIDE OF DASH)
DIODE 1 (BEHIND UPPER LEFT SIDE OF DASH)
FRONT FOG LAMP RELAY
FUSE
FUSE 36
FUSE 43
FUSE 45 FUSE 40 FUSE 38
FUSE 6 FUSE 1
FUSE 9
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
FUSIBLE LINK F
GENERATOR
GND LH HI GND PKB SW
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
H/L RH HI H/L RH HI FUSE IGN
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HID CONT
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN
HOT IN ON OR START
HOT IN ON OR START HOT IN ON OR ACC
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEADLAMP (HIGH)
LOW (HALOGEN)
LOW (XENON)
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP (HIGH)
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Headlights circuit, with drl -> AUTO LIGHT SENSOR (ON UPPER
Wiring diagram auto light sensor (on upper (2 of 2)
70 67 BAT GND
AUTO LIGHT SENSOR (ON UPPER
BEHIND HEADLIGHT)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
COMBINATION METER
COMBINATION SWITCH (LIGHTING SWITCH)
ENGINE ROOM (IPDM E/R) (ON RIGHT FRONT OF ENGINE COMPT,
FRONT FOG LAMP RELAY
FUSE 36
FUSE 38
FUSE 40
FUSE 43
FUSE 45
FUSE 6 FUSE 1
FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
FUSIBLE LINK F
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HID CONT
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START HOT IN ACC OR ON
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
INTELLIGENT POWER DISTRIBUTION MODULE
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEADLAMP (HIGH)
LOW (HALOGEN)
LOW (XENON)
OUT PUT 5
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
PNK 3 2 1 GND OUT POWER WIRE
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP (HIGH)
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlights circuit, without drl -> AUTO LIGHT SENSOR (ON UPPER
