Nissan Altima L31 facelift (2004-2006) 39 40 22 can-h can-l pwr window serial link pnk Wiring diagram

37 38 11 13 12 1 KEY SW IGN SW 39 40 22 CAN-H CAN-L PWR WINDOW SERIAL LINK PNK WIRE 48 47 RL DOOR SW DR SW DR 49 48 PNK CAN-L CAN-H WIRE 5 4 14 UNLOCK SW LOCK SW 57 66 59 65 63 62 56 70 BAT FUSE DOOR UNLOCK OUT (AS/RR) DOOR UNLOCK OUT (DR) BETWEEN FULL STROKE, N BLK WIRE BLK/RED WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) COM CYLINDER SWITCH) FULL STROKE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) 6 14 PNK WIRE DOOR LOCK OUT (ALL) ROOM LAMP OUT STEP LAMP OUT BAT SAVER OUT BAT DOOR LOCK, UNLOCK SWITCH FULL STROKE FUSE 1 FUSE 21 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (ON LEFT FRONT OF ENGINE COMPT, NEAR BATTERY) FUSIBLE LINK GRN WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INSERTED IPDM E/R (ON RIGHT FRONT OF ENGINE COMPT, BEHIND HEADLIGHT) KEY SWITCH, KEY LOCK SOLENOID (ON RIGHT SIDE OF STEERING COLUMN) LEFT FRONT DOOR LOCK ASSEMBLY (KEY BETWEEN FULL STROKE, N LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR SILL) LEFT REAR DOOR SWITCH (AT LEFT REAR DOOR SILL) LOCK LOCK SW LOCK SWITCH LT BLU WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PPL RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE REMOVED RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR SILL) RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH RIGHT REAR DOOR SWITCH (AT RIGHT REAR DOOR SILL) RR DOOR SW DR SW AS KEY RING ILL OUTPUT UNLOCK UNLOCK LEFT FRONT DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR) UNLOCK LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR) UNLOCK LOCK UNLOCK RIGHT FRONT DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR) UNLOCK RIGHT REAR DOOR LOCK ACTUATOR UNLOCK SWITCH WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
