Nissan Altima L31 (2001-2004) tilt up/ slide closed tilt dn/ slide open Wiring diagram
This page shows the only wiring diagram for the component.tilt up/ slide closed tilt dn/ slide open, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tilt up/ slide closed tilt dn/ slide open (1 of 1)
BLK WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
FUSE 12
FUSE 6
FUSE BLOCK (LEFT END OF DASH)
FUSE F
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
HOT IN ON, START
IGN
J/C 1 (BEHIND UPPER LEFT SIDE DASH)
ORG/ WIRE
POWER WINDOW POWER SUPPLY (BAT)
POWER WINDOW POWER SUPPLY (RAP)
PPL
SUN ROOF MOTOR ASSEMBLY (ON FRONT CENTER OF ROOF)
SUN ROOF SWITCH
TILT UP/ SLIDE CLOSED TILT DN/ SLIDE OPEN
TILT UP/ SLIDE CLOSED TILT DOWN/ SLIDE OPEN
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Power top/sunroof circuits -> TILT UP/ SLIDE CLOSED TILT DN/ SLIDE OPEN
