Nissan Altima L31 (2001-2004) rr def sw gnd 2 gnd 3 gnd 1 Wiring diagram
This page shows the only wiring diagram for the component.rr def sw gnd 2 gnd 3 gnd 1, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr def sw gnd 2 gnd 3 gnd 1 (1 of 1)
35 70 71 7 36 69 27 63 8 IGN CAN H CAN L BAT
A/C AUTO AMPLIFIER
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
FUSE 12 FUSE 6
FUSE 36 FUSE 35
FUSE AND FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) FUSE
FUSE BLOCK (UNDER FUSE 8
GRN WIRE
GRN/RED WIRE
GRN/YEL (OR GRY) WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
JOINT CONNECTOR 1 (UPPER LEFT SIDE OF DASH)
PPL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER CONDENSER (BASE OF LEFT "C" PILLAR)
REAR WINDOW DEFOGGER RELAY (BEHIND LEFT END OF DASH)
REAR WINDOW DEFOGGER SWITCH LEFT DOOR MIRROR
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT DOOR MIRROR
RR DEF SW GND 2 GND 3 GND 1
W/ AUTO A/C
W/O AUTO A/C
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Defogger circuit -> RR DEF SW GND 2 GND 3 GND 1
