Nissan Altima L31 (2001-2004) gnd ign 2 fan f/b fan gate Wiring diagram
This page shows the only wiring diagram for the component.gnd ign 2 fan f/b fan gate, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd ign 2 fan f/b fan gate (1 of 1)
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 VACTR COMP ON
A/C AUTO AMPLIFIER (BEHIND LEFT CENTER OF DASH)
A/C PD CUT
AIR MIX DOOR MOTOR (BEHIND LOWER LEFT CENTER OF DASH, ON HVAC ASSEMBLY)
AMBIENT SENSOR (BEHIND LOWER LEFT SIDE OF FRONT GRILLE)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND LOWER RIGHT SIDE OF DASH)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CANADA
COMBINATION METER
FAN CONTROL AMPLIFIER (BEHIND LOWER RIGHT SIDE OF DASH)
FUSE 10
FUSE 11
FUSE 12
FUSE 19
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GND IGN 2 FAN F/B FAN GATE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IN-VEHICLE SENSOR (ON LEFT CENTER OF DASH, NEAR IGNITION SWITCH)
INTAKE DOOR MOTOR (BEHIND RIGHT CENTER OF DASH, ON HVAC ASSEMBLY)
INTAKE SENSOR (BEHIND RIGHT SIDE OF DASH, ON HVAC ASSEMBLY)
J/C 1 (BEHIND UPPER LEFT SIDE OF DASH)
LAN SIG
LIGHT + LIGHT - BAT IGN VAC
LT GRN WIRE
MODE DOOR MOTOR (BEHIND LEFT CENTER OF DASH, ON HVAC ASSEMBLY)
ORG/ WIRE
ORG/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SENS GND SUN SENS W/T SENS CELSIUS/FAHRENHEIT
SOLID STATE
SUNLOAD SENSOR (ON UPPER RIGHT SIDE OF DASH, NEAR BASE OF WINDSHIELD)
UNIFIED METER CONTROL UNIT (WITH ODO/TRIP METER
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> 3.5l, automatic a/c circuit (1 of 2) -> GND IGN 2 FAN F/B FAN GATE
