Nissan Altima L31 (2001-2004) engine controls system anti-brake system wiper/ washer system Wiring diagram
This page shows the only wiring diagram for the component.engine controls system anti-brake system wiper/ washer system, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls system anti-brake system wiper/ washer system (1 of 1)
ACCESSORY RELAY
AIR CONDITIONING SYSTEM
ANTI-THEFT, ENGINE CONTROLS SYSTEM
BLK WIRE
BLK/RED WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
CPU FUSE 49 FUSE 50
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM ANTI-BRAKE SYSTEM WIPER/ WASHER SYSTEM
ENGINE CONTROLS, HEADLIGHTS SYSTEM
FROM FUSE 41 (DIAGRAM 1 OF 2)
FROM FUSE 51 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK C (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK M (DIAGRAM 1 OF 2)
FROM IGNITION SWITCH (DIAGRAM 2 OF 2)
FUEL PUMP RELAY
FUSE 12 FUSE 1
FUSE 13
FUSE 14
FUSE 15
FUSE 19
FUSE 20
FUSE 32
FUSE 33 TO FRONT WIPER HI RELAY (DIAGRAM 1 OF 2)
FUSE 42
FUSE 44 FUSE 45 FUSE 46
FUSE 48 FUSE 47
FUSE 6 FUSE 11 FUSE 10
FUSE 7 FUSE 5
FUSE 9 FUSE 8
GRN WIRE
GRY WIRE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
HEADLIGHTS SYSTEM
HEADLIGHTS, ANTI-THEFT SYSTEM
IGNITION RELAY
IGNITION SWITCH
OFF
ORG/ WIRE
POWER SOCKET
PPL
RED WIRE
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, ANTI-LOCK BRAKES, EXTERIOR LIGHTS SYSTEM
TRANSMISSIONS, ENGINE CONTROLS, HEADLIGHTS, STARTING/ CHARGING SYSTEM
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> ENGINE CONTROLS SYSTEM ANTI-BRAKE SYSTEM WIPER/ WASHER SYSTEM
