Nissan Altima L31 (2001-2004) check qa- Wiring diagram
This page shows the only wiring diagram for the component.check qa-, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram check qa- (1 of 1)
AVCC BAT
BLK WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR (PHASE) (ON REAR OF CYLINDER HEAD)
CHECK QA-
COMBINATION METER
CRANKSHAFT POSITION SENSOR (POS) (ON RIGHT REAR OF CYLINDER BLOCK)
CRUISE CONTROL SYSTEM
ENGINE CONTROL MODULE (BEHIND GLOVE BOX)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
FGAGE+ FTPRS ASCD
FGAGE-
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUSE 24
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENG COMPT)
GND-E IVC GND-E VB
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN ON OR START
INJ 1 INJ 2 INJ 3 INJ 4
J/C 5 (BEHIND UPPER RIGHT END OF DASH)
KNK PDPRES TA
KNOCK SENSOR (LOWER RIGHT SIDE OF CYLINDER BLOCK)
LT GRN/BLK WIRE
MALFUNCTION INDICATOR LAMP
NCA WIRE
ORG/ WIRE
PHASE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
TF POS QA+ TPS 1 TPS 2
TRANSMISSION CONTROL MODULE (BEHIND RIGHT END OF DASH)
UNIFIED METER CONTROL UNIT
VB MOTRLY VMOT MOTOR 1 GND-M MOTOR 2
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 2.5ls (4 of 4) -> CHECK QA-
