Nissan Altima L31 (2001-2004) air bag diagnostic sensor unit rear window defogger Wiring diagram
This page shows the only wiring diagram for the component.air bag diagnostic sensor unit rear window defogger, which is found in the car Nissan Altima L31 (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag diagnostic sensor unit rear window defogger (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT
AIR BAG DIAGNOSTIC SENSOR UNIT
AIR BAG DIAGNOSTIC SENSOR UNIT REAR WINDOW DEFOGGER
BLK WIRE
CONDENSER 1
CONDENSER 2, ENGINE CONTROL MODULE, IGNITION COIL 2, 4, 6
ELECTRIC THROTTLE CONTROL ACTUATOR, KNOCK SENSOR
ENGINE CONTROL MODULE (ECM)
GENERATOR
PARK/NEUTRAL POSITION SWITCH, ENGINE CONTROL MODULE, IGNITION COIL 1, 3, 5
W/ 2.5L
W/ 3.5L
Go to component -> Ground distribution circuit -> AIR BAG DIAGNOSTIC SENSOR UNIT REAR WINDOW DEFOGGER
