Nissan Altima L30 facelift (1999-2001) left rear com- bination lamp turn Wiring diagram
This page shows the only wiring diagram for the component.left rear com- bination lamp turn, which is found in the car Nissan Altima L30 facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear com- bination lamp turn (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
COMBINATION SWITCH (CORNERING LAMP SWITCH)
COMBINATION SWITCH (LIGHTING SWITCH)
FUSE 14
FUSE 34
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HIGH MOUNTED STOP LAMP (W/ REAR SPOILER)
HIGH MOUNTED STOP LAMP (W/O REAR SPOILER)
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT FRONT COMBI- NATION LAMP CORNERING
LEFT REAR COM- BINATION LAMP TURN
OFF
PARKING
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RH LH
RIGHT FRONT COMBI- NATION LAMP CORNERING
RIGHT LICENSE PLATE LAMP LEFT LICENSE PLATE LAMP
RIGHT REAR COM- BINATION LAMP TURN
SIDE MARKER
STOP
STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
STOP TAIL
TAIL
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT REAR COM- BINATION LAMP TURN
