Nissan Altima L30 (1997-1999) temp gauge Wiring diagram
This page shows the only wiring diagram for the component.temp gauge, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp gauge (1 of 1)
A/T ONLY
A/T W/ ASCD ONLY
ABS CONTROL UNIT (BEHIND LEFT KICK PANEL)
ABS IND.
AIR BAG IND
AIRBAG DIAGNOSTIC SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
ASCD CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE IND
BRN (OR BRN/WHT) WIRE
BRN WIRE
BRN/WHT WIRE
CANADA
CHARGE IND
CRUISE IND
DOOR IND
EXTERIOR LIGHTS SYSTEM (LEFT SIDE OF DASH) INTERIOR LIGHTS SYSTEM
FUEL GAUGE
FUEL IND
FUEL TANK GAUGE UNIT (IN FUEL TANK)
FUSE 12
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GENERATOR OIL PRESSURE SWITCH (ON RIGHT SIDE OF ENGINE, NEAR OIL FILTER)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
HI-BEAM IND
HOT IN ON OR START
ILLUMINATION (4 BULBS)
INSTRUMENT CLUSTER
LEFT "C" PILLAR)
LEFT TURN IND
MALFUNCTION IND LIGHT
O/D OFF IND
OIL IND
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PNK/BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TURN IND
SEAT BELT BUCKLE SWITCH
SEAT BELT IND
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
SPEED- OMETER
TACH- OMETER
TEMP GAUGE
TRANSMISSION CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
USA
VEHICLE SPEED SENSOR (ON TRANSAXLE)
WARNING CHIME UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK (OR YEL/BLU) WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit -> TEMP GAUGE
