Nissan Altima L30 (1997-1999) right rear com- bination lamp turn Wiring diagram
This page shows the only wiring diagram for the component.right rear com- bination lamp turn, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear com- bination lamp turn (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
COMBIN- ATION LAMP
COMBINATION FLASHER UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
COMBINATION SWITCH (LIGHTING SWITCH)
FUSE 11
FUSE 14
FUSE 20
FUSE 34
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD
HAZARD SWITCH
HIGH MOUNTED STOP LAMP (W/ REAR SPOILER)
HIGH MOUNTED STOP LAMP (W/O REAR SPOILER)
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (UNDER LEFT SIDE OF DASH)
HOT IN ON OR START
INSTRUMENT CLUSTER
LEFT "C" PILLAR)
LEFT FRONT COMBIN- ATION LAMP
LEFT LICENSE LAMP
LEFT REAR COM- BINATION LAMP
LEFT TURN IND
LT GRN/BLK WIRE
MULTI-REMOTE CONTROL RELAY 1 (BEHIND LEFT SIDE OF DASH)
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RH LH
RIGHT FRONT COMBIN- ATION LAMP
RIGHT FRONT COMBIN- ATION LAMP LEFT FRONT
RIGHT LICENSE LAMP
RIGHT REAR COM- BINATION LAMP TURN
RIGHT TURN IND
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TAIL STOP
TURN SIGNAL SWITCH
TURN STOP TAIL
W/ MULTI REMOTE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> RIGHT REAR COM- BINATION LAMP TURN
